Name: VSIPP-6DIRG-I2
SKU: 20452557
Price: 195.45 AUD
Availability: OutOfStock

Description

DESCRIPTION

The Professional AI Series identifies people & vehicles using machine learning, to reduce false motion detection alerts and provide meaningful video event notifications in real-time. When used in conjunction with a VIP Vision NVR, person and vehicle events can be isolated in footage playback to improve surveillance efficiency.

Camera features:

Stream up to 6.0MP (3072 x 1728) at 25fps
2.8mm fixed lens with 97° viewing angle
H.265 encoding for efficient storage & streaming
Up to 30m infrared range; true day/night (auto ICR)
Built-in microphone and microSD slot for edge recording
AI powered perimeter protection & smart motion detection (SMD 4.0)
Set up AI people and vehicle detection, receive alerts and search footage by people or vehicles
AI weather and anti-flicker scene self-adaption
Back/highlight compensation & true WDR (120dB)
3D digital noise reduction & auto white balance
IP67 weather rated housing for outdoor use

Specifications

Camera

Image Sensor: 1/2.7’’ 6.0MP Progressive Scan CMOS
Max. Resolution: 6.0 Megapixel
Effective Pixels: 3072 (H) x 1728 (V)
RAM / ROM: 1GB / 128MB
Min Illumination: 0.005 Lux/F1.5 (Color)
S/N Ratio: > 56dB
Infrared System: 2 x Infrared LED, 30m range, Auto/manual on/off control

Lens

Lens Type: Fixed
Lens / Iris: 2.8mm Fixed Focal Lens with Fixed Iris
Field of View: Horizontal: 97°, Vertical: 71°
Focus: Focus / 1.1m Min. Focus Distance

DORI

Detect (25px/m): 64m
Observe (63px/m): 25m
Recognise (125px/m): 13m
Identify (250px/m): 6m

Video

Resolution: 6.0MP (3072 x 1728) to CIF (352 x 288)
Frame Rate (Main): 6.0MP (1 ~ 25fps) / 4.0MP (1 ~25fps)
Frame Rate (Sub): D1 (1 ~ 25fps)
Frame Rate (Third): 1080p (1 ~ 25fps)
Video Compression: H.265 / H.264 / H.264B / MJPEG
Bit Rate: H.265: 19 ~ 8192Kbps / H.264: 32 ~ 8192Kbps
Bit Rate Control: Constant bit rate (CBR) / Variable bit rate (VBR)
Day/Night: Auto (ICR) / Color / B&W
Lighting Compensation: BLC / HLC / WDR (120dB) / AI SSA
Smart Scene Adaptive (SSA): No
White Balance: Auto / Natural / Street Lamp / Outdoor / Manual / Regional Custom
Gain Control: Auto
Noise Reduction: 3D DNR
Picture Control: Mirror / Flip (0°, 90°, 180°, 270°) (Support 90°/270° with 2.0MP resolution)

IVS

Intelligent Functions: Motion Detection (4 zones), Region of Interest (4 zones), Privacy Masking (4 zones), Smart Infrared
Perimeter Protection: Tripwire & Intrusion (Add recognition of humans & vehicles)
Face Detection: N/A
Face Attributes: N/A
People Counting: N/A
Heat Map: N/A
Event Trigger: Motion Detection, Video Tampering , Scene Changing, Network Disconnection, IP Address Conflict, Illegal Access, Storage Anomaly
Intelligent Search: Via NVR Smart Search, Search tripwire/ intrusion events by people or vehicle

Network

Ethernet: RJ-45 (10/100Base-T)
Protocol: IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; SNMP
Streaming Method: Unicast / Multicast
Max. User Access: 20 Users

Interface

Video Interface: N/A
Audio Interface: Built-in Mic / Audio Compression – G.711a; G.711Mu; G726; G.723; PCM
Alarm Interface: N/A
RS485: N/A
Edge Storage: MicroSD Card (up to 256GB) / NAS
Interoperability: ONVIF / P2P / CGI / Milestone / Genetec

Environmental
