Description
DESCRIPTION
The Tranquil 120 PWM FAN
TRANQUIL & POWERFUL
- Unique fan blade and frame design offers powerful airflow with low noise accomplished.
EXQUISITE CRAFTSMANSHIP
- Minimal clearance between fan frame and blades, achieving maximum operational efficiency.
Fluid Dynamic Bearing
- Reduces friction between shaft and bearing for longer life and minimal noise.
VIBRATION-ABSORBING & ANTI-NOISE PADS
- Equipped with eight damping feet to prevent resonance, reducing noise effectively.
CABLE & CONNECTOR
- Durable Woven Wire
- Covered with durable wovenwire to enhance the lifetime & create unique aesthetics.
- 4-Pin PWM Daisy Chain Cable
- Cable Length: 500 mm
- PWM Extension Cable Included
SPECIFICATIONS
- Model Name Tranquil 140
- Fan Type PWM Fan
- Dimensions 140 x 140 x 25 mm
- Bearing Type FDB
- Fan Speed 450±100~1500±150 RPM
- Airflow 21.13~85.96 CFM
- Air Pressure 0.11~1.79 mmH₂O
- Fan Noise Level 18.6~27.5 dB(A)
- Lifespan 50,000 hours / 25℃
- Connector 4-pin PWM
- Rated Voltage DC 12 V
- OperationVoltage DC 7-13.8 V
- Rated Current 0.12 (MAX:0.18) A
