K8630

Description

DESCRIPTION

The CR-Touch Sensor has been designed as a levelling solution based on users feedback. Compared with the traditional automatic levelling, it is compatible with more 3D printer platforms, more stable and cost-effective. It features a metal probe, which reduces wear and tear and greatly prolongs its service life.

After the electromagnetic component is powered on, the probe is extended under suction. When the probe touches the printing platform, the photoelectric sensor on the PCB board detects the contact signal, and the system records the current height of the platform. The sensor is compatible with PE I, stickers, glass, metal and more printing platform materials. Installing the sensor is very easy, simply download the CR touch program from the Creality 3D offical website and copy it to to the TF/SD card. Insert it directly into the card slot of the 3D printer. The program can be updated after power on.

Features

• Multi-point detection
• Smart compensation
• High precision
• Low power consumption
• Easy to install
• Strong compatibility
• Stable function

Specifications

• Applicable Models: All FDM printers
• Product Name: CR Touch
• Size: 27 x 17.5 x 39.3mm
• Accuracy: Positioning accuracy ≤0.04
• Product Weight: ~11.5g
• Operating temperature: ≤65°C
• Service Life: About 100,000 probe detection times
• Work Rate: <1W
• Rated Voltage: 5V
• Probe Route: 6mm

*Specifications are subject to change without notice.
