GV-N5070WF3OC-12G

Description

DESCRIPTION

GigabyteGeForce RTX™ 5070 WINDFORCE OC SFF 12G, 2542 MHz, CUDA 6144, 28 Gbps, GDDR7, 192 bit, PCI-E 5.0, PSU 750W, DisplayPort 2.1b *3 HDMI 2.1b *1

SPECIFICATION

• Graphics Processing: GeForce RTX™ 5070
• Core Clock: 2542 MHz (Reference card : 2512 MHz)
• CUDA® Cores: 6144
• Memory Clock: 28 Gbps
• Memory Size: 12 GB
• Memory Type: GDDR7
• Memory Bus: 192 bit
• Card Bus: PCI-E 5.0
• Digital max resolution: 7680×4320
• Multi-view: 4
• Card size: L=282 W=110 H=50 mm
• PCB Form: ATX
• DirectX: DirectX 12 API
• OpenGL: 4.6
• Recommended PSU: 750W
• Power Connectors: 16 Pin*1
• Output:
  • DisplayPort 2.1b *3
  • HDMI 2.1b *1
• Accessories
  • Quick guide
  • 1x 12V-2×6 to 2x PCIe 8pin adapter

FEATURES

• Powered by the NVIDIA Blackwell architecture and DLSS 4
• Powered by GeForce RTX 5070
• Integrated with 12GB GDDR7 192bit memory interface
• WINDFORCE cooling system
• Hawk fan
• Server-grade thermal conductive gel
• NVIDIA SFF-ready
• Reinforced structure

NVIDIA Blackwell Architecture

• The Ultimate Platform for Gamers and Creators

Fifth-Gen Tensor Cores

• Max AI performance with FP4 and DLSS 4

New Streaming Multiprocessors

• Optimized for neural shaders

Fourth-Gen Ray Tracing Cores

• Built for Mega Geometry

WINDFORCE COOLING SYSTEM

• The WINDFORCE cooling system delivers exceptional thermal performance through a combination of cutting-edge technologies. It features server-grade thermal conductive gel, innovative Hawk fans with alternate spinning, composite copper heat pipes, a large copper plate, 3D active fans, and screen cooling.

HAWK FAN

• The Hawk Fan features a unique blade design inspired by the aerodynamics of an eagle's wing. This design reduces air resistance and noise levels, resulting in up to a 53.6% increase in air pressure and a 12.5% increase in air volume without compromising acoustics.

GRAPHENE NANO LUBRICANT

• Graphene nano lubricant can extend the life of sleeve bearing fan by 2.1 times, close to the life of double ball bearing, and is quieter.

ALTERNATE SPINNING

• Reduce the turbulence of adjacent fans and increase airflow pressure.

3D ACTIVE FAN

• The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.

SERVER-GRADE THERMAL CONDUCTIVE GEL

• To enhance product quality and reliability, we have introduced server-grade thermal conductive gel for cooling critical components such as VRAM and MOSFETs. This highly deformable, non-fluid gel provides optimal contact for uneven surface and effectively resists deformation from transport or long-term use, unlike traditional thermal pads.

LARGE COPPER PLATE & COMPOSITE COPPER HEAT PIPE

• The large copper plate directly contacts the GPU, coupled with the composite copper heat pipes, which quickly transfers the heat of the GPU and VRAM to the heatsink.

SCREEN COOLING

• Extended heatsink allows air to pass through, providing better heat dissipation.

EXCELLENCE IN ESSENTIAL

NVIDIA SFF-READY

• Complying with NVIDIA's small form factor specification, our graphics cards pack powerful performance into a small form factor, achieving the perfect balance of size and power.

REINFORCED STRUCTURE

• The reinforced metal backplate with a bent edge, securely fastened to the I/O bracket, provides exceptional structural integrity.
