S1060C

$1.85

is available on purchases between $10 and $2,000 learn more

SPST Red Push On Mini Pushbutton Switch

2 in stock

SKU: 19726773 Category:

Description

DESCRIPTION

These handy miniature push buttons are ideal for any simple low current circuit switching. Red actuator with normally open push button action.

Specifications

  • Circuit: A: (ON)-OFF
  • Rating: 1A 125V ac / 0.5A 250V ac
  • Contact resistance: 30mΩ Max
  • Insulation resistance: 500V DC 100mΩ Min
  • Dielectric Strength: 1000V AC 1 Minute
  • Electrical Life: 5000 cycle
  • Mechanical Life: 10,000 cycle
  • Terminal Material: Copper, Alloy, (Silver or Gold Plated)
  • Push Force: >0.3kg
  • Soldering: 240° for 3 seconds
  • Mounting hole diameter: 7.3mm

*Specifications are subject to change without notice.
